145°C MELTDOWN! 😱 SAVING A ‘STONE-COLD DEAD’ NINTENDO SWITCH V1 (SHORT VERSION)

In this video, I’m breaking down a complete repair on a stone-cold dead Nintendo Switch V1 that refuses to take a charge. We go from initial teardown and diagnostics using a USB tester to hunting down a massive short that caused a literal meltdown on the board.

The Diagnostic Journey
We start with the basics, using a USB-C tester and the Mechanic USB tail insertion tester to check for signs of life. When a console pulls zero amps, it’s a clear signal that something is blocking the power rail. Using FlexBV Pro in butterfly mode, I’m able to trace the fault from the USB-C port straight to the charging fuse and the M92T36 chip.

The “Monster” Under the Thermal Camera
Things got intense when I discovered a component hitting a staggering 145°C. That’s enough heat to start melting thermal pads! The culprit? A total meltdown of the BQ24193 battery charger chip. I’ll show you how to safely remove this “monster” and install a fresh replacement without scorching the surrounding plastic

————————————————————
TIMESTAMP

00:00 START
00:08 INTRO
00:20 DISCLAIMER
00:29 THE ISSUE
02:21 DISASSEMBLING THE CONSOLE
02:44 BOOT UP CHECK WITH EXTERNAL BATTERY
03:22 SCHEMATIC & COMPONENT INSPECTION
04:29 TESTING THE CONSOLE
05:24 REMOVING THE MOTHERBOARD FROM THE CHASSIS
06:17 REMOVING THE BQ24193
07:22 RETEST THE CONSOLE
08:39 FULL ASSEMBLY OF THE CONSOLE
10:03 OUTRO

————————————————————
TOOLS USED IN THE VIDEO

– Mechanic USB Tail Insertion Tester : https://www.aliexpress.com/item/1005005868580489.html?channel=twinner
– USB Tester : https://www.aliexpress.com/item/1005004852976163.html?channel=twinner
– iFixit Spudger : https://www.ifixit.com/products/spudger
– CreationSpace CS0802A Electric Drill Screwdriver Dual-purpose Mini Electric Screwdriver Set Cordless Drilling … https://www.aliexpress.com/item/1005008045227133.html?channel=twinner
– FlexBV : https://pldaniels.com/flexbv5/ – Discord Server : https://discord.gg/UBTYU526M
– FNIRSI DMT-99 Digital Display Professional DMT99 Multimeter 10000 Counts True RMS Auto AC DC Tester Smart Volt… https://www.aliexpress.com/item/1005006431909009.html?channel=twinner
– 10pcs Micro LF 0402 SMD Fuse 0.5A 500mA 0.75A 1A 1.5A 2A 2.5A 3A 5A 32V FF Very Fast Acting 435 Surface Mount … https://www.aliexpress.com/item/4000222232143.html?channel=twinner
– BQ24193 : https://westingames.com/product/charging-ic-chips-bq24193-fix-parts-replacement-for-nintendo-swtich/
– Infiray T3S : InfiRay Xinfrared T3S T3pro Thermal Camera Industrial Thermal Imaging Camera for Smart Phones Android Type C https://www.aliexpress.com/item/1005007451021006.html?channel=twinner
– Mechanic IX5 Ultra Universal Preheating Platform Mobile Phone Motherboard Layered Bonding Glue Removal Dot Mat… https://www.aliexpress.com/item/1005007493895441.html?channel=twinner
– QUICK Original 861DW 1000W Heat Gun Lead Free Hot Air Soldering Station Rework Station+Nozzle With Replace Hot… https://www.aliexpress.com/item/1005006127355430.html?channel=twinner
-Stirri V3 Flux : https://stirri.com/products/v3-tf-tacky-flux-no-clean?variant=51329681031485

————————————————————
