MOD KIT INSTALLATION UPDATE (0 ╚ ≡ D)
This video is the latest update on how to install the mod kit on the 0 ╚ ≡ D
▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬
TIME STAMP
00:00:00 START
00:13:04 INTRO
00:24:08 DISCLAIMER
00:33:12 PREREQUISITES
00:51:07 PREPARING THE MICRO SD CARD
01:13:26 GETTING THE SOFTWARE
01:42:05 UPDATING THE CONSOLE
02:35:19 INSTALLING A SCREEN PROTECTOFD
03:22:20 DISASSEMBLING THE CONSOLE
06:09:02 CLAMPING THE MOTHERBOARD
06:55:12 INSTALLING THE DAT0 ADAPTER
09:21:23 SOLDERING THE B (RST) POINT
09:42:05 REMOVING THE CPU COVER
11:00:08 EXPOSING & SOLDERING THE D (CLK) POINT
12:28:06 SOLDERING THE A (CMD) POINT
12:58:10 SOLDERING THE 3.3V POINT
13:27:09 SOLDERING THE CPU FLEX RIBBON CABLE
14:48:05 PLACING THE MOD KIT
15:30:26 SOLDERING THE WIRES
16:48:05 INSTALLING THE MAGNETIC REED SWITCH
18:09:25 TESTING THE DIODE VALUE
18:36:26 PLACING THE MOTHERBOARD BACK TO THE CHASSIS
20:00:07 TESTING THE REED SWITCH & MOD KIT TRAINING PROCEDURE
21:50:24 RE-ASSEMBLE THE CONSOLE
22:56:16 TESTING THE HATS PACK
23:22:19 HOW TO RESET THE CHIP USING A MAGNET
▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬
TOOLS
1. iFixit Y00 screwdriver
2. iFisit PH00 screwdriver
3. Spudger
4. Plastic opener tool
5. Paper towel
6. Wipes Cleaning Cloth
7. Relife RL1000 PCB Cleaner / Isopropyl Alcohol 99%
8. Kester 275 Lead Free solder 0.4MM (.015″)
9. Amtech NC-559-V3-TF Flux
10. MaAnt D1 Mini Grinder
11. Tweezers
12. Bent Nose Plier
13. HY510 Thermal paste
14. Hakko FX-951 Solder Station with T12-BC1 Tip
15. Surgery Scalpel #20
16. UL10064 AWG36 Wire
17. GPS-11A NO-type Magnetic Reed Switch
18. Kapton tape (5mm & 5cm)
19. 3M 9448A 10mm width, 0.15mm thick
20. V4 Mod Kit for the OLED
21. Eakins Autofocus Microscope 180x magnification 0.5X Barlow Lens
22. Sunshine Plier SS-109
23. Sunshine SS-022B Double Head Brush
24. PCB Holder T12-Pro
▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬
